Glass Reactor

Jacketed glass reactors are commonly used for chemical synthesis, process development, filtration, purification, evaporation, stirring, dissolving, mixing, and extracting operations across a host of science disciplines. Our jacketed glass reactor vessel range in size from 1 liter to 200 liters, from Lab scale to commercial scale. Its durable glass material allows for easy observation and analysis, ensuring accurate results. With its versatile design, it offers a wide range of applications in various industries.

Series	JGR-L	JGR-EVP	JGR-FK	JGR-F
Application	Reaction	Reaction; Evaporation	Reaction; Crystallization; Filtration	Reaction; Filtration
Volume	1L, 2L, 5L, 10L, 20L, 30L, 50L, 80L, 100L, 150L, 200L or custom sizes.	10L, 20L, 30L, 50L, 80L, 100L, 150L, or custom sizes.	5L, 10L, 20L, 30L, 50L, 80L, or custom sizes.	5L, 10L, 20L, 30L, 50L, 80L, or custom sizes.
Sealing	Mechanical sealing	Mechanical sealing	Mechanical sealing	Mechanical sealing
Temperature Control
Temperature Range	-120°C~250°C	-120°C~250°C	-120°C~250°C	-120°C~250°C
Heating Method	Jacket circulating heating	Jacket circulating heating	Jacket circulating heating	Jacket circulating heating
Stirring
Standard Motor	●	●	●	●
Explosion-proof Motor	○	○	○	○
Air Driven / Pneumatic Motor	○	○	○	○
Stirring Speed	1, 2L: 0-1200rpm; >2L: 0-600rpm	0-600rpm	0-600rpm	0-600rpm
Structure
Ports	≤5L: 5 ports; 10-200L: 6 ports	6 ports	5L: 5 ports; 10-100L: 6 ports	5L: 5 ports; 10-100L: 6 ports
Condenser	1 piece	2 pieces	2 pieces	1 piece
Collection Tank	N/A	●	N/A	N/A
Mother Liquid Collection Vessel	N/A	●	●	N/A
Filter Plate	N/A	●	●	●

Series

JGR-L

JGR-EVP

JGR-FK

JGR-F

Application

Reaction

Reaction; Evaporation

Reaction; Crystallization; Filtration

Reaction; Filtration

Volume

1L, 2L, 5L, 10L, 20L, 30L, 50L, 80L, 100L, 150L, 200L or custom sizes.
