5L Benchtop Bioreactor for Cell Culture with 4 Gas Inlets BR100-C1
Got questions?
Feel free to get in touch
Couldn't load pickup availability
The BR100-C1 offers a 5L benchtop bioreactor perfect for microbial fermentation. It has two gas inlets, enabling improved oxygenation and mixing to maximize cell yields. Its automation system and operational flexibility make it an ideal solution for professional fermentation applications.
Specification:
Items Included:
- Control Console: BR100-C1
- Culture Vessel: 5L Boro3.3 glass vessel with top mechanical stirring (25~75%working volume), SS316L cover
- Sensors: PT100, DO, foam, pH
- Feeding Pumps: 4 peristaltic pump heads, controlled
- Gas Inlet
- Sparger from the bottom (Air + O2 + N2 + CO2): controlled by rotameter and electromagetic valve;
- Overlay (air): manually controlled by rotameter
- Heating & Cooling: Heated by bottom electric hot plate; cooled by stainless steel cooling tube (chilled water)
- Accessories: 4 supplement bottles, SS316L feeding needle, etc.
- Consumables: O-rings, fuses, silicone stoppers, inlet air filter, vent filter, 20m silicone tubing, etc.
Functions Included:
- Temperature
- Robust PID algorithm;
- Electrical-heating by SS316L electric hot plate at vessel bottom, chilled by tap or chilled water supply;
- Sequential control coupled with fermentation process
- pH
- pH control coupled with peristaltic pump or CO2;
- Manual pH control by peristaltic pump
- DO
- Cascade control, coupled with different parameters (gasinlet and peristaltic pump)
- Agitation
- Robust PID algorithm;
- Manual speed control or speed control coupled with other parameters;
- Foam
- Foam control coupled with peristaltic pump; (anti-foam);
- Mechanial defoaming blade;
- Feeding (peristaltic pump)
- Accumulation volume control;
- Manual control; Or control by plan or pre-set curve;
- Coupled with other parameters (DO, pH, etc)
- Fermentation Sequence
- Pre-set fermentation sequences along with timeline (pH, DO, agitation, temperature, etc)
- Others
- Historical data export and curves;
- Fermentation/culture batch record;
- Calibration of sensors and peristaltic pumps;
- 3-level authority setting & control;
- Record historical operations
